USE OF THE BH CURVES APPROXIMATION FOR THE CALCULATION OF MAGNETIC CIRCUITS IN ELECTRICAL MACHINES
DOI:
https://doi.org/10.59277/RRST-EE.2023.68.1.7Keywords:
BH curves, Approximation, Electrical steel, Electrical machines, Magnetic circuits, Magnetic voltageAbstract
For the design of electrical machines, electrical steel BH curves are usually used in tabular or graphical form in magnetic circuit calculations. This is not convenient for the digitization of data and increases the requirement for computational accuracy. In this work, a partial approximation of the BH curves by the exponential function is proposed. The accuracy of the results obtained relative to the total approximation of these curves is demonstrated. The method for calculating the coefficients of the approximation functions is given. Application use of these curves is modeled in calculating the magnetic voltage of the trapezoidal-shaped stator tooth in AC machines. Finally, a numerical calculation example is carried out according to the proposed method.
References
(1) O.D. Goldberg, I.S. Sviridenko. Engineering design of electrical machines. Moscow, Academia (2008).
(2) H.A. Weiss, P. Trӧber, R. Golle, S. Steentjes, N. Leuning, S. Elfgen, K. Hameyer: Impact of Punching Parameter Variations on Magnetic Properties of Nongrain-Oriented Electrical Steel. IEEE Trans On Industry Applications, 54, 6 (2018).
(3) ***IEC 404: Magnetic materials–part 2: Methods of measurement of the magnetic properties of electrical steel sheet and strip by means of an Epstein frame. IEC Standard (1996).
(4) G. Paltanea, V. Manescu (Paltanea), I.V. Nemoianu, H. Gavrila, M.I. Dascalu, V. Turcin, C. Paun: Quasi-static magnetic properties of iron-nickel based soft alloys. Rev. Roum. Sci. Techn.– Électrotechnique et Énergétique 65, 3–4, pp. 153–156, Bucarest, (2020).
(5) L. Petrescu, V. Ionita, E. Cazacu, M.C. Petrescu: Power losses estimation for FeSi sheets using algebraic models. Rev. Roum. Sci. Techn.– Électrotechn. et Énerg., 64, 1, pp. 23–26, Bucarest (2019).
(6) ***IEC 404: Magnetic materials–Part 3: Methods of measurement of the magnetic properties of magnetic sheet and strip by means of a single sheet tester. IEC Standard, 1992.
(7) ***European Standard. Designation systems for steels - Part 1. EN 10027-1. (2005).
(8) J. Pyrhӧnen, T. Jokinen, V. Hrabovcová. Design of Rotating Electrical Machines. John Wiley & Sons (2008).
(9) M.G. Каsyanеnко, V.F. Матyuchоv, M.A. Vaganov: Approximation of magnetization curves of electrical steels in the design of electrical machines. Izvistia SPEU «LETI» № 9/2018.
(10) A.A. Mohammadi, A.C. Pop, J. Gyselinck. An Approach for the BH Curve Identification of Magnetic Core of Synchronous Reluctance Machines. IEEE Trans. Magn., 57, 1 (2021).
(11) T.A. Lipo, Introduction to AC machine design. IEEE Press, Wiley (2017).
